ASTM B564 Inconel 625 / UNS N06625 / DIN 2.4856 Nickel Alloy Steel RTJ Flange

Brand Name : YUHONG

Model Number : Inconel 625 / UNS N06625 / DIN 2.4856

Certification : ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015

Place of Origin : China

MOQ : 3 Pieces

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : According To Customers' Request

Delivery Time : 5 - 60 work days

Packaging Details : Ply-wooden Case / Pallet

Standard : ASTM B564 / ASME SB564

Material Grade : Inconel 625 / UNS N06625 / DIN 2.4856

Size : 1/2"-48"

Pressure : Class150-2500/ PN6-PN100

Technics : Froged

Application : Petroleum,chemical,fittings and connection

Contact Now

ASTM B564 Inconel 625 / UNS N06625 / DIN 2.4856 Nickel Alloy Steel RTJ Flange

Inconel Flanges have resistant to oxidation, and this nickel-base alloy functions well at elevated temperatures. In fact, its properties remain unchanged over an extensive temperature range. And like most Inconel alloys, this material has resistant to stress related corrosion cracking to chloride ions. The main applicances of Inconel 625 Forging Flanges include industries like marine and petroleum industries. Other advantages of using the Inconel 625 Flanges are high fracture toughness as well as fabricability.

Equivalent Grades:

STANDARD GOST AFNOR EN WERKSTOFF NR. UNS JIS BS
Inconel 625 ХН75МБТЮ NC22DNB4M NC22DNB4M 2.4856 N06625 NCF 625 NA 21

Specification: Inconel 625 Flanges
Pressure Rating 2500 LBS, Class 150 LBS, 900 LBS, 1500 LBS, 300 LBS, 600 LBS
common types Forged / Threaded / Screwed / Plate
Connect Type/ Flange Face Type Raised Face (RF) Flanges, Large Tongue & Groove Flanges, Flat Face (FF) Flanges, Large Male-Female (LMF) Flanges, Groove Flanges, Lap-Joint Face (LJF) Flanges, Small Male-Female (SMF) Flanges, Small Tongue Flanges, Ring Type Joint (RTJ) Flanges
Coating Oil Black Paint, Anti-rust Paint, Zinc Plated, Cold and Hot Dip Galvanized, Yellow Transparent,
Production technique Forged, Heat treated and machined
Size Chart 1/2" to 48"

Chemical Composition:

Ni C Fe Si Mn S Al Ti Nb + Ta P Mo Cr2
58 min 0.1 max 5 max 0.5 max 0.5 max 0.015 max 0.4 max 0.4 max 3.15–4.15 0.015 max 8-10 20-23

Mechanical Strength:

Tensile Strength Yield Strength (0.2%Offset) Elongation Density Melting Point
Psi – 1,35,000 , MPa – 930 Psi – 75,000 , MPa – 517 42.5 % 8.4 g/cm3 1350 °C (2460 °F)

Applications:

Pipeline

High Temperature Application

Water Pipe Line

Nuclear Power Plants

Food Processing and Dairy Industries

Boiler & Heat Exchangers

ASTM B564 Inconel 625 / UNS N06625 / DIN 2.4856 Nickel Alloy Steel RTJ Flange
